SET e3TX 2+1+RX Multi

e3TX

The FISHTRON E3TX offers a revolutionary simple multi-functional operation. In short, no unnecessary features or complicated setup.This higher version is equipped with a transmitter which means it is fully compatible with the RX MULTI,RX SIX and RX MINI receivers as well as with the WRL1 and WRL2 LED lamps.

The unique design along with FLAJZAR electronics with accurate magnetic line scanning ensures high quality processing, durability and long battery life. By unwinding the line forward and backward, the pulley rotates and the electronics with contactless magnetic sensoring translates this movement into electrical impulses. The output is then a sound signal and an optical signal consisting of a series of four LED RGB diodes, which you can select to a desired level and colour. The indicating speed of the LED diodes is dependant on the speed of the line unwinding. So is the sound signal.

With the FISHTRON e3TX you can change the LED colours to blue, green, red and purple. The FISHTRON E3  is powered by two LR1 (LADY) batteries that are located under the battery cover at the back of the device. The swinger connector can be found at the bottom of the device.
With the dimensions of 99 x 48 x 31 mm, the FISHTRON e3TX is one of the smallest bite alarms on the market.
This indicator has been developed and produced in the Czech Republic, as well as all of the FLAJZAR devices and they are all included with our 3 year warranty.

Specification:
- Multifunctional optical signalling consisting of multiple colour LEDs, flash memory
- Audible signalling with strength control
- volume and pitch control - all with one rotating element (knob)
- Swinger connector
- Dimensions - height without the screw 84mm, width 48mm, depth 50mm, screw length 15mm
- 2x battery LR-01
- power consumption off-state 0.00mA, on (idle) up to 15uA (microAmper), on (shooting) max. 200mA dia. impulsively
- connectors for swinger connection - JACK 2.5 mm mono, centre wire + voltage max. 3V, load max 5mA.

RX MULTI
It recognises the bite, speed and direction of the unwinding fishing line, as well as the assigned LED colour as the new feature. The receiver indicates everything visually and acoustically by different tone heights (depending on the bite alarm settings).

The receiver contains 3 alarm channels that work with the ALF3 fishing alarms.
- attractive design with rubber coated body which fits and sits well in the hand
- you can wear it around your neck or stand it on the table
- reliable reception and displaying of bites from up to four FISHTRON Q9-RGB TX, NEON TX3, CATFISH TX3, e3TX bite alarms
- possibility to connect up to three wireless ALF3 alarm sensors
- built-in LED lamp
- modern electronics, powered by only one AAA cell (regular battery) = cheap operation
- intelligent battery status indication informs about the need of battery replacement well in advance
- wireless lamps WRL1 and WRL2, WRL3 controlling possibility
- When you turn the beacon on or off, the listening tone will let you know
- During capture, the alarm from the ALF 3 sensors is automatically blocked and after 3 minutes it is unblocked again.
- Possibility to set the alarm volume ALF3
- Low battery audible alarm

CONTAINS:
2x e3TX
1x RX MULTI
1x CASE
